¹⁵⁷Tb   ¹⁵⁸Tb   ¹⁵⁹Tb   ¹⁶⁰Tb

Go to isotope

Total MACS at 30keV:

1817

±

258

mb

Cross sections do not include stellar enhancement factors!

Version	Total MACS [mb]	Partial to gs [mb]	Partial to isomer [mb]
1.0	1817 ± 258	-	-
0.0	1580 ± 150	-	-

(Version 0.0 corresponds to Bao et al.)

New rec. value is average of evaluated libraries (endfb71,jendl40). Uncertainty is deviation of both libraries. There is a discrepancy between the existing measurements, an independent activation measurement would be desirable.
Last review: September 2013

original	renorm.	year	type	Comment	Ref
1471 ± 66		1992	c	VdG, TOF, Au+Ag+Nd+etc.:Sat.	BKP92
1800 ± 100		1978	c	Linac, TOF, 6Li+10B:INK79	MMH78
2949 ± 442 E(n)= 23 (5) keV		1974	c	Sb-Be, Act., 1/v(E), 127I:832 (26) mb (24 keV)	SSR74
1850 ± 250	1765	1972	c	VdG, TOF, In:740 (70) mb	LDM72
2080		2011	e	ENDF/B-VII.1	endfb71
1558		2011	e	JENDL-4.0	jendl40
1801		2004	e	JEFF-3.1	jeff31
2081		2002	e	JENDL-3.3	jendl33
2200 ± 200		1971	e		AGM71
1116		2005	t	MOST 2005	Gor05
2949		2002	t	MOST 2002	Gor02
1427		2000	t	NON-SMOKER	RaT99
1975		1981	t		Har81
1610		1976	t		HWF76

Original:MACS [<σ v>/v_T] (mb) for kT=30 keV, based on the published cross sections except where indicated otherwise.
Renorm:MACS [<σ v>/v_T] (mb) for kT=30 keV for which the reference or standard cross section was meanwhile improved.
Type: The letters and numbers in the column labelled 'type' give information on how the cross section has been obtained:

c	Directly quoted from the reference itself
e	Evaluated value taken directly from the reference
t	Theoretical value

Energy	5keV	8keV	10keV	15keV	20keV	25keV	30keV	40keV	50keV	60keV	80keV	100keV
MACS	4875 ± 851	-	3323 ± 573	2664 ± 431	2276 ± 348	2012 ± 295	1817 ± 258	1544 ± 211	1358 ± 181	1220 ± 159	1029 ± 128	898 ± 106
Xfactor	1.00	1.00	0.99	0.96	0.91	0.85	0.78	0.67	0.58	0.51	0.40	0.32
SEF	1.00	1.00	1.00	1.01	1.02	1.02	1.03	1.04	1.05	1.07	1.08	1.08
Rate	2.89	-	2.79	2.76	2.74	2.73	2.72	2.70	2.69	2.67	2.63	2.58

MACS:
Reference: endfb71,jendl40
Procedure: 'e+t' (The MACS from kT=5 keV to 100 keV are derived from calculated cross sections, which are then normalized to experimental data, e.g. to the values at kT=25 keV obtained in activation measurements. In these cases the uncertainties should be linearly increased below 25 and above 30 keV to reach about 30% at the extreme kT values.)
Year: 2013

X-factor:
Reference: Rau12
Year: 2012

SEF (Stellar enhancement factor):
Reference: Rau09
Year: 2009
Comment:

Rate:
Reaction rate N_A<σv> given in 10⁸ cm³/mole/s, including SEF

	159Ho 33.05 m β+ 160Ho 25.60 m β+ 161Ho 2.48 h β+ 162Ho 15.00 m β+ 163Ho 4.57 ka 2125 mb, β+ 158Dy 0.1 1060 mb 159Dy 144.44 d β+ 160Dy 2.34 890 mb 161Dy 18.91 1964 mb 162Dy 25.51 446 mb 157Tb 71.01 a β+ 158Tb 179.99 a β+ 159Tb 100 1580 mb 160Tb 72.30 d 3240 mb, β- 161Tb 6.91 d β- 156Gd 20.47 615 mb 157Gd 15.65 1369 mb 158Gd 24.84 324 mb 159Gd 18.48 h β- 160Gd 21.86 154 mb 155Eu 4.75 a 1320 mb, β- 156Eu 15.19 d β- 157Eu 15.18 h β- 158Eu 45.90 m β- 159Eu 18.10 m β-
