⁷⁸Kr   ⁷⁹Kr   ⁸⁰Kr   ⁸¹Kr   ⁸²Kr   ⁸³Kr   ⁸⁴Kr   ⁸⁵Kr   ⁸⁶Kr

Go to isotope

Total MACS at 30keV:

249

±

13

mb

Cross sections do not include stellar enhancement factors!

Version	Total MACS [mb]	Partial to gs [mb]	Partial to isomer [mb]
1.0	249 ± 13	-	-
0.0	243 ± 15	-	-

(Version 0.0 corresponds to Bao et al.)

New rec. value is weighted average of MBB05 and WLK86. Uncertainty in MBB05 is only statistical, assumed 5% total uncertainty. New MACS vs. kT table is normalized average from recently evaluated databases (jendl40, endfb71, jeff32). TENDL-2015 is discrepant. There is an additional uncertainty introduced in the MACS vs. kT table from the deviation of the evaluations, which can be as high as 10% for kT= 5 keV.
Last review: December 2016

original	renorm.	year	type	Comment	Ref
255 ± 4	255 ± 13	2004	c	Linac, TOF, 131Xe	MBB05
251 ± 16	243 ± 15	1986	r	VdG, TOF, Au:B-V norm. by 613 mb/601 mb= 1.02	WLK86
346.3		2015	e	TENDL-2015 using the TALYS code	tendl15
240.8		2014	e	JEFF-3.2 using calculations from TENDL-2012	jeff32
267.8		2011	e	ENDF/B-VII.1	endfb71
265.8		2011	e	JENDL-4.0	jendl40
322.4		2004	e	JEFF-3.1	jeff31
267.3		2002	e	JENDL-3.3	jendl33
225		1971	s		AGM71
170		2005	t	MOST 2005	Gor05
412		2002	t	MOST 2002	Gor02
314		2000	t	NON-SMOKER	RaT99
237		1986	t		WLK86
259		1981	t		Har81
540		1978	t		WFH78

Original:MACS [<σ v>/v_T] (mb) for kT=30 keV, based on the published cross sections except where indicated otherwise.
Renorm:MACS [<σ v>/v_T] (mb) for kT=30 keV for which the reference or standard cross section was meanwhile improved.
Type: The letters and numbers in the column labelled 'type' give information on how the cross section has been obtained:

c	Directly quoted from the reference itself
r	Recalculated for kT = 30keV with the code described in Ref. 2 after renormalizing the original data to updated standard cross sections
e	Evaluated value taken directly from the reference
s	Semiempirical estimates given in the reference
t	Theoretical value

Energy	5keV	8keV	10keV	15keV	20keV	25keV	30keV	40keV	50keV	60keV	80keV	100keV
MACS	848 ± 95	-	543 ± 54	410 ± 36	334 ± 25	284 ± 18	249 ± 13	203 ± 10	173 ± 8	152 ± 7	126 ± 5	109 ± 4
Xfactor	0.91	0.84	0.79	0.72	0.68	0.65	0.63	0.61	0.59	0.58	0.56	0.56
SEF	0.98	0.97	0.97	0.96	0.97	0.97	0.97	0.97	0.97	0.97	0.97	0.96
Rate	4.95	-	4.41	4.08	3.84	3.65	3.51	3.31	3.16	3.04	2.90	2.80

MACS:
Reference: MBB05,WLK86,jendl40,endfb71,jeff32
Procedure: 'e+t' (The MACS from kT=5 keV to 100 keV are derived from calculated cross sections, which are then normalized to experimental data, e.g. to the values at kT=25 keV obtained in activation measurements. In these cases the uncertainties should be linearly increased below 25 and above 30 keV to reach about 30% at the extreme kT values.)
Year: 2016

X-factor:
Reference: Rau12
Year: 2012

SEF (Stellar enhancement factor):
Reference: Rau09
Year: 2009
Comment:

Rate:
Reaction rate N_A<σv> given in 10⁷ cm³/mole/s, including SEF

	83Sr 1.35 d β+ 84Sr 0.56 368 mb 85Sr 64.84 d β+ 86Sr 9.86 64 mb 87Sr 7 92 mb 82Rb 1.27 m β+ 83Rb 86.20 d β+ 84Rb 33.10 d β+ 85Rb 72.17 234 mb 86Rb 18.64 d 202 mb, β- 81Kr 229.02 ka 607 mb, β+ 82Kr 11.58 90 mb 83Kr 11.49 243 mb 84Kr 57 38 mb 85Kr 10.72 a 55 mb, β- 80Br 17.68 m β- 81Br 49.31 239 mb 82Br 1.47 d β- 83Br 2.40 h β- 84Br 31.80 m β- 79Se 294.99 ka 263 mb, β- 80Se 49.61 42 mb 81Se 18.45 m β- 82Se 8.73 9 mb 83Se 22.30 m β-
