⁷⁹Br   ⁸⁰Br   ⁸¹Br   ⁸²Br

Go to isotope

Total MACS at 30keV:	661	±	44	mb
Partial c.s. to isomer:	181	±	18	mb

Cross sections do not include stellar enhancement factors!

Version	Total MACS [mb]	Partial to gs [mb]	Partial to isomer [mb]
1.0	661 ± 44	-	181 ± 18
0.3	622 ± 34	-	171 ± 17
0.0	627 ± 42	-	78 ± 8

(Version 0.0 corresponds to Bao et al.)

New recomm. value is from WBK86b (normalized by 683/657= 1.04) and HKU08b (normalized by by 632/586= 1.0785) to correct for new 197Au cross sections. MACS vs. kT table from energy dependencies of jeff32 which fits the data perfectly, and normalized energy dependencies of endfb71 and jendl40. Additional uncertainties for MACS vs. kT tables from differences between evaluations. Recomm. partial cross section to isomer is deduced from isomeric ratio IR=0.274 HKU08b.
Last review: December 2016

original	renorm.	year	type	Comment	Ref
613 ± 59	661 ± 64	2008	c	VdG, Act., Au:RaK88 corrected by 632/586= 1.0785	HKU08b
741 ± 30		1988	c	Linac, TOF, 6Li, Au:Sat.	Mac88a
636 ± 42	661 ± 44	1986	c	VdG, Act., 1/v(kT), Au: renorm. by 683 mb/657 mb= 1.04 (kT= 25 keV)	WBK86b
636.3		2015	e	TENDL-2015 using the TALYS code	tendl15
660.7		2014	e	JEFF-3.2 using calculations from TENDL-2012	jeff32
687.8		2011	e	ENDF/B-VII.1	endfb71
700.2		2011	e	JENDL-4.0	jendl40
731.6		2004	e	JEFF-3.1	jeff31
687.8		2002	e	JENDL-3.3	jendl33
600 ± 150		1971	e		AGM71
421		2005	t	MOST 2005	Gor05
434		2002	t	MOST 2002	Gor02
436		2000	t	NON-SMOKER	RaT99
749		1981	t		Har81
520		1978	t		WFH78
Partial cross section to 80mBr:
174 ± 17	168 ± 16	2008	c	VdG, Act., Au:RaK88	HKU08b
79 ± 8	78	1984	c	VdG, Act., 1/v(kT), Au:657mb(25keV)	Wal84

Original:MACS [<σ v>/v_T] (mb) for kT=30 keV, based on the published cross sections except where indicated otherwise.
Renorm:MACS [<σ v>/v_T] (mb) for kT=30 keV for which the reference or standard cross section was meanwhile improved.
Type: The letters and numbers in the column labelled 'type' give information on how the cross section has been obtained:

c	Directly quoted from the reference itself
e	Evaluated value taken directly from the reference
t	Theoretical value

Energy	5keV	8keV	10keV	15keV	20keV	25keV	30keV	40keV	50keV	60keV	80keV	100keV
MACS	1890 ± 181	-	1223 ± 105	966 ± 74	823 ± 58	729 ± 49	661 ± 44	567 ± 38	503 ± 35	454 ± 33	383 ± 30	332 ± 27
Xfactor	1.00	1.00	1.00	1.00	1.00	1.00	1.00	0.98	0.94	0.89	0.76	0.64
SEF	1.00	1.00	1.00	1.00	1.00	1.00	1.00	1.00	0.99	0.99	0.97	0.95
Rate	1.12	-	1.03	1.00	0.98	0.97	0.96	0.95	0.94	0.92	0.88	0.84

MACS:
Reference: WBK86b,HKU08b,jeff32,endfb71,jendl40
Procedure: 'e+t' (The MACS from kT=5 keV to 100 keV are derived from calculated cross sections, which are then normalized to experimental data, e.g. to the values at kT=25 keV obtained in activation measurements. In these cases the uncertainties should be linearly increased below 25 and above 30 keV to reach about 30% at the extreme kT values.)
Year: 2016

X-factor:
Reference: Rau12
Year: 2012

SEF (Stellar enhancement factor):
Reference: Rau09
Year: 2009
Comment:

Rate:
Reaction rate N_A<σv> given in 10⁸ cm³/mole/s, including SEF
