Available isotopes for Selenium (Z=34)
Recommended MACS30 (Maxwellian Averaged Cross Section @ 30keV)
78Se 79Se
Cross sections do not include stellar enhancement factors! History
(Version 0.0 corresponds to Bao et al.) Comment
Rec. value is from DHK06b, recalculated with normalized energy dependency of tendl15 and corrected for the new 197Au cross section. MACS vs. kT table is from tendl15, uncertainty is 16% as in DHK06b.
Isotopic ratio at kT= 30 keV is IR= 0.604 (DHK06b,ID13b). The more recent data of IKK11 does not show any values for Se-78 in the paper, values only available as private communication to EXFOR. For this reason the values cannot be considered for the rec. value. Note that there is a large discrepancy between the activation measurement of DHK06b and the TOF measurement of IKK11, which is mirrored in the different results from the evaluations. More investigation needed. Last review: June 2016 List of all available values
Original:MACS [<σ v>/vT] (mb) for kT=30 keV, based on the published cross sections except where indicated otherwise. Renorm:MACS [<σ v>/vT] (mb) for kT=30 keV for which the reference or standard cross section was meanwhile improved. Type: The letters and numbers in the column labelled 'type' give information on how the cross section has been obtained:
MACS, SEF and Reaction Rates for different energies
MACS: Reference: DHK06b,tendl15 Procedure: 'e+t' (The MACS from kT=5 keV to 100 keV are derived from calculated cross sections, which are then normalized to experimental data, e.g. to the values at kT=25 keV obtained in activation measurements. In these cases the uncertainties should be linearly increased below 25 and above 30 keV to reach about 30% at the extreme kT values.) Year: 2016 X-factor: Reference: Year: SEF (Stellar enhancement factor): Reference: Year: Comment: Rate: Reaction rate NA<σv> given in 107 cm3/mole/s, including SEF Chart of nuclei
Isotope: Selenium
|
