¹⁵⁴Dy   ¹⁵⁶Dy   ¹⁵⁸Dy   ¹⁵⁹Dy   ¹⁶⁰Dy   ¹⁶¹Dy   ¹⁶²Dy   ¹⁶³Dy   ¹⁶⁴Dy

Go to isotope

Total MACS at 30keV:

1626

±

126

mb

Cross sections do not include stellar enhancement factors!

Version	Total MACS [mb]	Partial to gs [mb]	Partial to isomer [mb]
1.0	1626 ± 126	-	-
0.3	1607 ± 92	-	-
0.0	1567 ± 145	-	-

(Version 0.0 corresponds to Bao et al.)

New recommended cross section is recalculated from DDH09 using recent evaluated libraries (endfb71 and jendl40). Uncertainty is 7.2 % as in DDH09 plus deviation of both libraries.
Last review: October 2013

original	renorm.	year	type	Comment	Ref
1626 ± 126		2009,2013	c	VdG, Act., Au:RaK88; recalc. using endfb71 and jendl40	DDH09
1633 ± 118		2009	c	VdG, Act., Au:RaK88	DDH09
1589 ± 145	1567	1985	c	VdG, Act., 1/v(kT), Au:657 mb (25 keV)	Bee85
1533		2011	e	ENDF/B-VII.1	endfb71
1481		2011	e	JENDL-4.0	jendl40
870		1971	s		AGM71
2126		2005	t	MOST 2005	Gor05
2010		2002	t	MOST 2002	Gor02
1190		2000	t	NON-SMOKER	RaT99
850 ± 280		1988	t		ZZC88
1637		1981	t		Har81
1840		1976	t		HWF76

Original:MACS [<σ v>/v_T] (mb) for kT=30 keV, based on the published cross sections except where indicated otherwise.
Renorm:MACS [<σ v>/v_T] (mb) for kT=30 keV for which the reference or standard cross section was meanwhile improved.
Type: The letters and numbers in the column labelled 'type' give information on how the cross section has been obtained:

c	Directly quoted from the reference itself
e	Evaluated value taken directly from the reference
s	Semiempirical estimates given in the reference
t	Theoretical value

Energy	5keV	8keV	10keV	15keV	20keV	25keV	30keV	40keV	50keV	60keV	80keV	100keV
MACS	4665 ± 411	-	2962 ± 258	2331 ± 189	1991 ± 149	1777 ± 130	1626 ± 126	1424 ± 118	1293 ± 110	1198 ± 102	1068 ± 88	983 ± 80
Xfactor	1.00	1.00	1.00	1.00	0.99	0.97	0.92	0.79	0.66	0.55	0.40	0.31
SEF	1.00	1.00	1.00	1.00	1.00	1.01	1.03	1.09	1.14	1.20	1.28	1.34
Rate	2.77	-	2.48	2.40	2.37	2.39	2.44	2.59	2.77	2.94	3.24	3.50

MACS:
Reference: DDH09,jendl40,endfb71
Procedure: 'e+t' (The MACS from kT=5 keV to 100 keV are derived from calculated cross sections, which are then normalized to experimental data, e.g. to the values at kT=25 keV obtained in activation measurements. In these cases the uncertainties should be linearly increased below 25 and above 30 keV to reach about 30% at the extreme kT values.)
Year: 2013

X-factor:
Reference: Rau12
Year: 2012

SEF (Stellar enhancement factor):
Reference: Rau09
Year: 2009
Comment:

Rate:
Reaction rate N_A<σv> given in 10⁸ cm³/mole/s, including SEF

	156Er 19.50 m β+ 157Er 18.65 m β+ 158Er 2.29 h β+ 159Er 36.00 m β+ 160Er 1.19 d β+ 155Ho 48.00 m β+ 156Ho 56.00 m β+ 157Ho 12.60 m β+ 158Ho 11.30 m β+ 159Ho 33.05 m β+ 154Dy 3.00 Ma α 155Dy 9.90 h β+ 156Dy 0.06 1607 mb 157Dy 8.14 h β+ 158Dy 0.1 1060 mb 153Tb 2.34 d β+ 154Tb 21.50 h β+ 155Tb 5.32 d β+ 156Tb 5.35 d β+ 157Tb 71.01 a β+ 152Gd 0.2 1049 mb 153Gd 240.41 d 4550 mb, β+ 154Gd 2.18 1028 mb 155Gd 14.8 2648 mb 156Gd 20.47 615 mb
