¹⁵¹Eu   ¹⁵²Eu   ¹⁵³Eu   ¹⁵⁴Eu   ¹⁵⁵Eu   ¹⁵⁶Eu

Go to isotope

Total MACS at 30keV:

2567

±

177

mb

Cross sections do not include stellar enhancement factors!

Version	Total MACS [mb]	Partial to gs [mb]	Partial to isomer [mb]
1.0	2567 ± 177	-	-
0.2	2556 ± 46	-	-
0.0	2780 ± 100	-	-

(Version 0.0 corresponds to Bao et al.)

New rec. value is average from recent evaluations (endfb71,jendl40). Uncertainty is deviation between evaluations plus 2.9 % as in BKP92. There is a discrepancy between the activation measurement of BSA01 and the TOF measurements of BKP92 and MaY87a (f(TOF/Act)= 0.87-0.88). More investigations needed!
Last review: September 2013

original	renorm.	year	type	Comment	Ref
2710 ± 77	2807 ± 80	2001,2013	r	VdG, Act., 1/v(kT), Au:RaK88; renorm. using en.dep. of jendl40 and endfb71	BSA01
2710 ± 77		2001	c	VdG, Act., 1/v(kT), Au:RaK88; without SEF: BSA01	BSA01
2733 ± 110		1995	c	VdG, Act., 1/v(kT), Au:RaK88	Sto93
2447 ± 73		1992	c	VdG, TOF, Au+Ag+Nd+etc.:Sat.	BKP92
2630 ± 200		1990	c	Critical piles, 10B	BBM90
2480 ± 100		1987	c	Linac, TOF, 6Li, Au:Sat.	MaY87a
3000 ± 300		1979	b	Linac, TOF, 6Li+10B	MAN79
3459 ± 346	3206	1977	b	VdG, TOF, 10B:Mag75, Au:628 mb(kT= 30 keV)	KYM77
3119 ± 312		1976	b	Linac, TOF, 10B:Mag75, Au+Ag+Sm:Sat.	MEJ76
2671 ± 612		2011	e	ENDF/B-VII.1 incl. covariance data	endfb71
2466		2011	e	JENDL-4.0	jendl40
2471		2006	e	ENDF/B-VII.0	endfb7
2535		2004	e	JEFF-3.1	jeff31
2535		2002	e	JENDL-3.3	jendl33
2566		1981	e		KNM81
2700 ± 300		1971	e		AGM71
2587		2005	t	MOST 2005	Gor05
1582		2002	t	MOST 2002	Gor02
2905		2000	t	NON-SMOKER	RaT99
2814		1981	t		Har81
2840		1976	t		HWF76

Original:MACS [<σ v>/v_T] (mb) for kT=30 keV, based on the published cross sections except where indicated otherwise.
Renorm:MACS [<σ v>/v_T] (mb) for kT=30 keV for which the reference or standard cross section was meanwhile improved.
Type: The letters and numbers in the column labelled 'type' give information on how the cross section has been obtained:

r	Recalculated for kT = 30keV with the code described in Ref. 2 after renormalizing the original data to updated standard cross sections
c	Directly quoted from the reference itself
b	Calculated from smooth cross sections with model fit: ln(sigma) = a + a1 ln(E) + a2 ln^2(E)
e	Evaluated value taken directly from the reference
t	Theoretical value

Energy	5keV	8keV	10keV	15keV	20keV	25keV	30keV	40keV	50keV	60keV	80keV	100keV
MACS	7605 ± 542	-	4900 ± 358	3841 ± 287	3248 ± 236	2855 ± 202	2567 ± 177	2162 ± 143	1884 ± 121	1679 ± 106	1392 ± 84	1200 ± 69
Xfactor	1.00	1.00	1.00	0.99	0.97	0.93	0.88	0.78	0.67	0.58	0.44	0.34
SEF	1.00	1.00	1.00	1.00	1.00	0.99	0.98	0.94	0.91	0.88	0.86	0.85
Rate	4.51	-	4.11	3.95	3.85	3.75	3.64	3.42	3.22	3.05	2.83	2.71

MACS:
Reference: endfb71,jendl40
Procedure: 'e+t' (The MACS from kT=5 keV to 100 keV are derived from calculated cross sections, which are then normalized to experimental data, e.g. to the values at kT=25 keV obtained in activation measurements. In these cases the uncertainties should be linearly increased below 25 and above 30 keV to reach about 30% at the extreme kT values.)
Year: 2013

X-factor:
Reference: Rau12
Year: 2012

SEF (Stellar enhancement factor):
Reference: Rau09
Year: 2009
Comment:

Rate:
Reaction rate N_A<σv> given in 10⁸ cm³/mole/s, including SEF

	153Tb 2.34 d β+ 154Tb 21.50 h β+ 155Tb 5.32 d β+ 156Tb 5.35 d β+ 157Tb 71.01 a β+ 152Gd 0.2 1049 mb 153Gd 240.41 d 4550 mb, β+ 154Gd 2.18 1028 mb 155Gd 14.8 2648 mb 156Gd 20.47 615 mb 151Eu 47.81 3775 mb 152Eu 13.51 a 7600 mb, β+ 153Eu 52.19 2780 mb 154Eu 8.59 a 4420 mb, β- 155Eu 4.75 a 1320 mb, β- 150Sm 7.38 422 mb 151Sm 90.00 a 2710 mb, β- 152Sm 26.75 473 mb 153Sm 1.93 d 1095 mb, β- 154Sm 22.75 206 mb 149Pm 2.21 d 2510 mb, β- 150Pm 2.68 h β- 151Pm 1.18 d β- 152Pm 4.12 m β- 153Pm 5.25 m β-
