⁹⁶Ru   ⁹⁸Ru   ⁹⁹Ru   ¹⁰⁰Ru   ¹⁰¹Ru   ¹⁰²Ru   ¹⁰³Ru   ¹⁰⁴Ru   ¹⁰⁵Ru   ¹⁰⁶Ru

Go to isotope

Total MACS at 30keV:

171

±

11

mb

Cross sections do not include stellar enhancement factors!

Version	Total MACS [mb]	Partial to gs [mb]	Partial to isomer [mb]
1.0	171 ± 11	-	-
0.2	151 ± 7	-	-
0.0	186 ± 11	-	-

(Version 0.0 corresponds to Bao et al.)

Rec. value is the weighted average of the renormalized value from Rap02 and MaH80. New MACS vs. kT table is the normalized energy dependency from jeff32/endfb71/jendl40. Uncertainty towards kT=5 and 100 keV is the extrapolated uncertainty from the deviation between the libraries.
Last review: January 2017

original	renorm.	year	type	Comment	Ref
151 ± 7	163 ± 8	2002	c	VdG, Act., Au:RaK88 corrected by 632/586= 1.0785	Rap02
186 ± 11		1980	c,1	Linac, TOF, 6Li+235U:endfb52, Au:Sat., k=0.985	MaH80
313 ± 84	267	1973	c	Sb-Be, Act., 1/v(E), 127I: 832 mb (24keV)	MSR73
251.6		2015	e	TENDL-2015 using the TALYS code	tendl15
190.7		2014	e	JEFF-3.2	jeff32
190.7 ± 26.6		2011	e	ENDF/B-VII.1 incl. covariances	endfb71
189.6		2011	e	JENDL-4.0	jendl40
190.0		2004	e	JEFF-3.1	jeff31
189.8		2002	e	JENDL-3.3	jendl33
314		1981	e		KNM81
330 ± 50		1971	e		AGM71
224		2005	t	MOST 2005	Gor05
282		2002	t	MOST 2002	Gor02
146.9		2000	t	NON-SMOKER	RaT99
133		1981	t		Har81
91		1976	t		HWF76

Original:MACS [<σ v>/v_T] (mb) for kT=30 keV, based on the published cross sections except where indicated otherwise.
Renorm:MACS [<σ v>/v_T] (mb) for kT=30 keV for which the reference or standard cross section was meanwhile improved.
Type: The letters and numbers in the column labelled 'type' give information on how the cross section has been obtained:

c	Directly quoted from the reference itself
1	Including k from Ref. MaW81, where k is a correction factor which has been applied to the originally reported cross section
e	Evaluated value taken directly from the reference
t	Theoretical value

Energy	5keV	8keV	10keV	15keV	20keV	25keV	30keV	40keV	50keV	60keV	80keV	100keV
MACS	459 ± 50	-	327 ± 33	259 ± 24	218 ± 18	191 ± 14	171 ± 11	145 ± 11	129 ± 11	118 ± 11	105 ± 12	97 ± 13
Xfactor	1.00	1.00	1.00	1.00	1.00	1.00	1.00	1.00	1.00	1.00	0.98	0.95
SEF	1.00	1.00	1.00	1.00	1.00	1.00	1.00	1.00	1.00	1.00	1.00	1.01
Rate	2.73	-	2.75	2.67	2.59	2.54	2.49	2.44	2.42	2.43	2.50	2.61

MACS:
Reference: Rap02,MaH80 jeff32/endfb71/jendl40
Procedure: 'e+t' (The MACS from kT=5 keV to 100 keV are derived from calculated cross sections, which are then normalized to experimental data, e.g. to the values at kT=25 keV obtained in activation measurements. In these cases the uncertainties should be linearly increased below 25 and above 30 keV to reach about 30% at the extreme kT values.)
Year: 2017

X-factor:
Reference: Rau12
Year: 2012

SEF (Stellar enhancement factor):
Reference: Rau09
Year: 2009
Comment:

Rate:
Reaction rate N_A<σv> given in 10⁷ cm³/mole/s, including SEF
