²⁸Si   ²⁹Si   ³⁰Si   ³¹Si   ³²Si

Go to isotope

Total MACS at 30keV:

7.56

±

0.59

mb

Cross sections do not include stellar enhancement factors!

Version	Total MACS [mb]	Partial to gs [mb]	Partial to isomer [mb]
1.0	7.56 ± 0.59	-	-
0.2	6.58 ± 0.66	-	-
0.0	7.9 ± 0.9	-	-

(Version 0.0 corresponds to Bao et al.)

Rec. value is from GKD03 (previous rec. value included no DC component). MACS vs. kT table from GKD03, but extended above kT= 50 keV with norm. energy dependence from KAB76,BAM75b.
Last review: February, 2013

original	renorm.	year	type	Comment	Ref
7.56 ± 0.59		2003	c	Linac, TOF, Au: Sat.; DC component is 0.98 (69) mb	GKD03
7.9 ± 0.8		1976	r	Linac, TOF, 6Li, Au:Sat. Recalcul. including data of MDH81	KAB76,BAM75b
10.4		1971	s		AGM71
7.77 ± 0.83		2011	e	ENDF/B-VII.1	endfb71
7.77		2011	e	JENDL-4.0	jendl40
5.75		2002	e	JENDL-3.3	jendl33
6.44		2015	t	TENDL-2015 using the TALYS code	tendl15
63.8		2005	t	MOST 2005	Gor05
89.2		2002	t	MOST 2002	Gor02
8.82		2000	t	NON-SMOKER	RaT99
5.4		1978	t		WFH78

Original:MACS [<σ v>/v_T] (mb) for kT=30 keV, based on the published cross sections except where indicated otherwise.
Renorm:MACS [<σ v>/v_T] (mb) for kT=30 keV for which the reference or standard cross section was meanwhile improved.
Type: The letters and numbers in the column labelled 'type' give information on how the cross section has been obtained:

c	Directly quoted from the reference itself
r	Recalculated for kT = 30keV with the code described in Ref. 2 after renormalizing the original data to updated standard cross sections
s	Semiempirical estimates given in the reference
e	Evaluated value taken directly from the reference
t	Theoretical value

Energy	5keV	8keV	10keV	15keV	20keV	25keV	30keV	40keV	50keV	60keV	80keV	100keV
MACS	8.29 ± 0.84	11.22 ± 1.13	11.77 ± 1.19	11.30 ± 1.17	9.98 ± 1.08	8.67 ± 1.00	7.56 ± 0.95	5.99 ± 0.93	5.02 ± 0.96	3.88 ± 0.78	2.62 ± 0.52	1.94 ± 0.39
Xfactor	1.00	1.00	1.00	1.00	1.00	1.00	1.00	1.00	1.00	1.00	1.00	1.00
SEF	1.00	1.00	1.00	1.00	1.00	1.00	1.00	1.00	1.00	1.00	1.00	1.00
Rate	4.99	8.54	10.01	11.77	12.00	11.66	11.14	10.19	9.55	8.08	6.30	5.22

MACS:
Reference: KAB76,BAM75b,GDK03
Procedure: 'e' (The Maxwellian-averaged cross sections (MACS) from kT=5 keV to 100 keV are obtained from experimental data; the relative uncertainties are similar to those quoted for the 30 keV data.)
Year: 1976,2003

X-factor:
Reference: Rau12
Year: 2012

SEF (Stellar enhancement factor):
Reference: Rau09
Year: 2009
Comment:

Rate:
Reaction rate N_A<σv> given in 10⁵ cm³/mole/s, including SEF

	29S 187.00 ms β+ 30S 1.18 s β+ 31S 2.57 s β+ 32S 95.02 4.1 mb 33S 0.75 7.4 mb 28P 270.00 ms β+ 29P 4.14 s β+ 30P 2.50 m β+ 31P 100 1.74 mb 32P 14.26 d β- 27Si 4.16 s β+ 28Si 92.23 2.9 mb 29Si 4.683 7.9 mb 30Si 3.087 6.5 mb 31Si 2.62 h β- 26Al 717.12 ka 3.7 mb, β+ 27Al 100 3.74 mb 28Al 2.24 m β- 29Al 6.56 m β- 30Al 3.60 s β- 25Mg 10 6.4 mb 26Mg 11.01 0.126 mb 27Mg 9.46 m β- 28Mg 20.91 h β- 29Mg 1.30 s β-
