¹⁸⁰W   ¹⁸²W   ¹⁸³W   ¹⁸⁴W   ¹⁸⁵W   ¹⁸⁶W   ¹⁸⁷W   ¹⁸⁸W

Go to isotope

Total MACS at 30keV:

225

±

27

mb

Cross sections do not include stellar enhancement factors!

Version	Total MACS [mb]	Partial to gs [mb]	Partial to isomer [mb]
1.0	225 ± 27	-	-
0.3	223 ± 5	-	-
0.0	224 ± 10	-	-

(Version 0.0 corresponds to Bao et al.)

Rec. value is from MDD09b, recalculated with normalized average of evaluated libraries (jeff31,endfb71,jendl40). Uncertainty in MACS vs. kT table is 5.3% from MDD09b plus standard deviation from endfb71.
Last review: January 2014

original	renorm.	year	type	Comment	Ref
225 ± 27		2009,2013	r	VdG, Act., Au:RaK88; en. dep. from jeff31,endfb71,jendl40	MDD09b
222 ± 15		2009	c	VdG, Act., Au:RaK88	MDD09b
229 ± 11 E(n)= 31.5 (35) keV		1987	c	VdG, TOF, 7Li(p,n); Au+Ag+Nd+Ta+W:Sat.	BKK87
217 ± 6		1983	b	Linac, TOF, 6Li, Au:Sat.	MDA83
256 ± 10	238	1982	c	VdG, TOF, Au:B-IV	BKW82
252.2 ± 16.9		2011	e	ENDF/B-VII.1 incl. standard deviation	endfb71
244.2		2011	e	JENDL-4.0	jendl40
222.4		2006	e	ENDF/B-VII.0	endfb7
203.4		2004	e	JEFF-3.1	jeff31
203.4		2002	e	JENDL-3.3	jendl33
286 ± 38		1991	t		KJB91
180 ± 20		1971	e		AGM71
292		2005	t	MOST 2005	Gor05
324		2002	t	MOST 2002	Gor02
266		2000	t	NON-SMOKER	RaT99
234		1981	t		Har81
314		1976	t		HWF76

Original:MACS [<σ v>/v_T] (mb) for kT=30 keV, based on the published cross sections except where indicated otherwise.
Renorm:MACS [<σ v>/v_T] (mb) for kT=30 keV for which the reference or standard cross section was meanwhile improved.
Type: The letters and numbers in the column labelled 'type' give information on how the cross section has been obtained:

r	Recalculated for kT = 30keV with the code described in Ref. 2 after renormalizing the original data to updated standard cross sections
c	Directly quoted from the reference itself
b	Calculated from smooth cross sections with model fit: ln(sigma) = a + a1 ln(E) + a2 ln^2(E)
e	Evaluated value taken directly from the reference
t	Theoretical value

Energy	5keV	8keV	10keV	15keV	20keV	25keV	30keV	40keV	50keV	60keV	80keV	100keV
MACS	564.0 ± 29.5	-	358.0 ± 18.8	294.9 ± 15.5	262.6 ± 13.8	241.2 ± 12.7	224.7 ± 12.0	198.8 ± 11.1	178.6 ± 10.5	162.4 ± 9.9	138.4 ± 9.2	121.9 ± 8.7
Xfactor	1.00	1.00	1.00	0.99	0.97	0.92	0.84	0.68	0.55	0.45	0.32	0.24
SEF	1.00	1.00	1.00	1.00	1.01	1.03	1.06	1.12	1.18	1.23	1.33	1.44
Rate	3.34	-	3.00	3.03	3.15	3.30	3.46	3.73	3.94	4.11	4.38	4.64

MACS:
Reference: MDD09b,jeff31,endfb71,jendl40
Procedure: 'e+t' (The MACS from kT=5 keV to 100 keV are derived from calculated cross sections, which are then normalized to experimental data, e.g. to the values at kT=25 keV obtained in activation measurements. In these cases the uncertainties should be linearly increased below 25 and above 30 keV to reach about 30% at the extreme kT values.)
Year: 2013

X-factor:
Reference: Rau12
Year: 2012

SEF (Stellar enhancement factor):
Reference: Rau09
Year: 2009
Comment:

Rate:
Reaction rate N_A<σv> given in 10⁷ cm³/mole/s, including SEF

	184Os 0.02 590 mb 185Os 93.60 d β+ 186Os 1.59 422 mb 187Os 1.6 896 mb 188Os 13.29 399 mb 183Re 70.00 d β+ 184Re 38.00 d β+ 185Re 37.4 1535 mb 186Re 3.72 d 1550 mb, β- 187Re 41.20x109 y 1160 mb, β- 182W 26.5 274 mb 183W 14.31 515 mb 184W 30.64 223 mb 185W 75.10 d 703 mb, β- 186W 28.43 235 mb 181Ta 99.988 766 mb 182Ta 114.43 d 1120 mb, β- 183Ta 5.10 d β- 184Ta 8.70 h β- 185Ta 49.40 m β- 180Hf 35.08 179 mb 181Hf 42.39 d 194 mb, β- 182Hf 8.90 Ma 117 mb, β- 183Hf 1.07 h β- 184Hf 4.12 h β-
