¹⁸⁴Os   ¹⁸⁶Os   ¹⁸⁷Os   ¹⁸⁸Os   ¹⁸⁹Os   ¹⁹⁰Os   ¹⁹¹Os   ¹⁹²Os   ¹⁹³Os   ¹⁹⁴Os

Go to isotope

Total MACS at 30keV:

584

±

49

mb

Cross sections do not include stellar enhancement factors!

Version	Total MACS [mb]	Partial to gs [mb]	Partial to isomer [mb]
1.0	584 ± 49	-	-
0.3	590 ± 43	-	-
0.0	657 ± 202*	-	-

(Version 0.0 corresponds to Bao et al.)

New rec. value is recalculated from MDD09c with normalized energy dependencies of jeff30A,jendl40. Uncertainty is 7.2% from MDD09c plus deviation between both normalized evaluations.
Last review: March 2014

original	renorm.	year	type	Comment	Ref
584 ± 49		2009,2013	r	VdG, Act., Au:RaK88; en. dep. from jeff30A,jendl40	MDD09c
590 ± 43		2009	c	VdG, Act., Au:RaK88; en. dep. from NON-SMOKER RaT99	MDD09c
723.3		2011	e	JENDL-4.0	jendl40
400		1971	s		AGM71
705		2005	t	MOST 2005	Gor05
693		2002	t	MOST 2002	Gor02
789		2000	t	NON-SMOKER	RaT99
480		1981	t		Har81
869		1976	t		HWF76

Original:MACS [<σ v>/v_T] (mb) for kT=30 keV, based on the published cross sections except where indicated otherwise.
Renorm:MACS [<σ v>/v_T] (mb) for kT=30 keV for which the reference or standard cross section was meanwhile improved.
Type: The letters and numbers in the column labelled 'type' give information on how the cross section has been obtained:

r	Recalculated for kT = 30keV with the code described in Ref. 2 after renormalizing the original data to updated standard cross sections
c	Directly quoted from the reference itself
e	Evaluated value taken directly from the reference
s	Semiempirical estimates given in the reference
t	Theoretical value

Energy	5keV	8keV	10keV	15keV	20keV	25keV	30keV	40keV	50keV	60keV	80keV	100keV
MACS	1446 ± 191	-	980 ± 84	800 ± 60	700 ± 52	633 ± 50	584 ± 49	511 ± 50	459 ± 51	418 ± 51	359 ± 52	320 ± 52
Xfactor	1.00	1.00	1.00	1.00	0.98	0.94	0.88	0.74	0.60	0.50	0.36	0.28
SEF	1.00	1.00	1.00	1.00	1.00	1.02	1.04	1.08	1.14	1.18	1.26	1.33
Rate	8.57	-	8.22	8.22	8.34	8.53	8.79	9.30	9.78	10.14	10.73	11.29

MACS:
Reference: MDD09c,jeff30A,jendl40
Procedure: 'e+t' (The MACS from kT=5 keV to 100 keV are derived from calculated cross sections, which are then normalized to experimental data, e.g. to the values at kT=25 keV obtained in activation measurements. In these cases the uncertainties should be linearly increased below 25 and above 30 keV to reach about 30% at the extreme kT values.)
Year: 2013

X-factor:
Reference: Rau12
Year: 2012

SEF (Stellar enhancement factor):
Reference: Rau09
Year: 2009
Comment:

Rate:
Reaction rate N_A<σv> given in 10⁷ cm³/mole/s, including SEF

	184Pt 17.30 m β+ 185Pt 1.18 h β+ 186Pt 2.08 h β+ 187Pt 2.35 h β+ 188Pt 10.20 d β+ 183Ir 57.00 m β+ 184Ir 3.09 h β+ 185Ir 14.40 h β+ 186Ir 16.64 h β+ 187Ir 10.50 h β+ 182Os 22.10 h β+ 183Os 13.00 h β+ 184Os 0.02 590 mb 185Os 93.60 d β+ 186Os 1.59 422 mb 181Re 19.90 h β+ 182Re 2.67 d β+ 183Re 70.00 d β+ 184Re 38.00 d β+ 185Re 37.4 1535 mb 180W 0.12 660 mb 181W 121.20 d β+ 182W 26.5 274 mb 183W 14.31 515 mb 184W 30.64 223 mb
