¹⁷⁴Hf   ¹⁷⁶Hf   ¹⁷⁷Hf   ¹⁷⁸Hf   ¹⁷⁹Hf   ¹⁸⁰Hf   ¹⁸¹Hf   ¹⁸²Hf

Go to isotope

Total MACS at 30keV:

141

±

8

mb

Cross sections do not include stellar enhancement factors!

Version	Total MACS [mb]	Partial to gs [mb]	Partial to isomer [mb]
0.2	141 ± 8	-	-
0.0	117 ± 41*	-	-

(Version 0.0 corresponds to Bao et al.)

Rec. value is from activation measurement of VDH07. MACS vs. kT table is calculated with normalized evaluated value from jendl40 (f(norm)= 0.982).
Last review: January 2014

original	renorm.	year	type	Comment	Ref
141 ± 8		2007,2013	c	VdG, Act., Au:RaK88; using en.dep. from jendl40	VDH07
141 ± 8		2007	c	VdG, Act., Au:RaK88; using en.dep. from RaT99	VDH07
144.1		2011	e	JENDL-4.0	jendl40
120 ± 35 kT= 25 keV		2007	t	HFSM; priv. comm. A. Mengoni	VDH07
51 ± 25 kT= 25 keV		2007	t	CoH; priv. comm. T. Kawano	VDH07
59 kT= 25 keV		2007	t	TALYS; priv. comm. A. Koning	VDH07
270 kT= 25 keV		2007	t	EMPIRE; priv. comm. M. Herman	VDH07
53.8		2005	t	MOST 2005	Gor05
65.9		2002	t	MOST 2002	Gor02
125		2000	t	NON-SMOKER	RaT99
241		1981	t		Har81

Original:MACS [<σ v>/v_T] (mb) for kT=30 keV, based on the published cross sections except where indicated otherwise.
Renorm:MACS [<σ v>/v_T] (mb) for kT=30 keV for which the reference or standard cross section was meanwhile improved.
Type: The letters and numbers in the column labelled 'type' give information on how the cross section has been obtained:

c	Directly quoted from the reference itself
e	Evaluated value taken directly from the reference
t	Theoretical value

Energy	5keV	8keV	10keV	15keV	20keV	25keV	30keV	40keV	50keV	60keV	80keV	100keV
MACS	343	-	240	197	172	155	141 ± 8	121	107	96	80	69
Xfactor	1.00	1.00	1.00	0.99	0.94	0.87	0.78	0.61	0.48	0.39	0.27	0.20
SEF	1.00	1.00	1.00	1.00	1.02	1.04	1.07	1.14	1.21	1.28	1.42	1.55
Rate	2.03	-	2.01	2.03	2.08	2.15	2.20	2.32	2.43	2.52	2.69	2.84

MACS:
Reference: VDH07,jendl40
Procedure: 'e+t' (The MACS from kT=5 keV to 100 keV are derived from calculated cross sections, which are then normalized to experimental data, e.g. to the values at kT=25 keV obtained in activation measurements. In these cases the uncertainties should be linearly increased below 25 and above 30 keV to reach about 30% at the extreme kT values.)
Year: 2014

X-factor:
Reference: Rau12
Year: 2012

SEF (Stellar enhancement factor):
Reference: Rau09
Year: 2009
Comment:

Rate:
Reaction rate N_A<σv> given in 10⁷ cm³/mole/s, including SEF

	182W 26.5 274 mb 183W 14.31 515 mb 184W 30.64 223 mb 185W 75.10 d 703 mb, β- 186W 28.43 235 mb 181Ta 99.988 766 mb 182Ta 114.43 d 1120 mb, β- 183Ta 5.10 d β- 184Ta 8.70 h β- 185Ta 49.40 m β- 180Hf 35.08 179 mb 181Hf 42.39 d 194 mb, β- 182Hf 8.90 Ma 117 mb, β- 183Hf 1.07 h β- 184Hf 4.12 h β- 179Lu 4.59 h β- 180Lu 5.70 m β- 181Lu 3.50 m β- 182Lu 2.00 m β- 183Lu 58.00 s β- 178Yb 1.23 h β- 179Yb 8.00 m β- 180Yb 2.40 m β- 181Yb 1.00 m β-
