¹³³Cs   ¹³⁴Cs   ¹³⁵Cs   ¹³⁶Cs   ¹³⁷Cs

Go to isotope

Total MACS at 30keV:

163

±

10

mb

Cross sections do not include stellar enhancement factors!

Version	Total MACS [mb]	Partial to gs [mb]	Partial to isomer [mb]
1.0	163 ± 10	-	-
0.2	160 ± 10	-	-
0.0	198 ± 17	-	-

(Version 0.0 corresponds to Bao et al.)

Rec. value and MACS vs. kT table is from jendl40 which fits data from PDA04 perfectly. Assumed 6.3% uncertainty as in PDA04.
Last review: July 2013

original	renorm.	year	type	Comment	Ref
160 ± 10		2004	c	VdG, Act., Au:RaK88; en. dep. from endfb7	PDA04
198 ± 17		1997	c	VdG, Act., 1/v(kT), Au:RaK88	JKK97
201.5		2011	e	ENDF/B-VII.1	endfb71
162.9		2011	e	JENDL-4.0	jendl40
217.4		2004	e	JEFF-3.1	jeff31
201.4		2002	e	JENDL-3.3	jendl33
148		2005	t	MOST 2005	Gor05
189		2002	t	MOST 2002	Gor02
320		2000	t	NON-SMOKER	RaT99
234		1981	t		Har81
167		1976	t		HWF76

Original:MACS [<σ v>/v_T] (mb) for kT=30 keV, based on the published cross sections except where indicated otherwise.
Renorm:MACS [<σ v>/v_T] (mb) for kT=30 keV for which the reference or standard cross section was meanwhile improved.
Type: The letters and numbers in the column labelled 'type' give information on how the cross section has been obtained:

c	Directly quoted from the reference itself
e	Evaluated value taken directly from the reference
t	Theoretical value

Energy	5keV	8keV	10keV	15keV	20keV	25keV	30keV	40keV	50keV	60keV	80keV	100keV
MACS	529	-	335	257	212	183	163 ± 10	136	118	106	90	79
Xfactor	1.00	1.00	1.00	1.00	1.00	1.00	1.00	1.00	1.00	0.99	0.97	0.94
SEF	1.00	1.00	1.00	1.00	1.00	1.00	1.00	1.00	1.00	0.99	0.98	0.97
Rate	3.14	-	2.81	2.64	2.52	2.43	2.37	2.28	2.21	2.16	2.10	2.03

MACS:
Reference: PDA04,jendl40
Procedure: 'e+t' (The MACS from kT=5 keV to 100 keV are derived from calculated cross sections, which are then normalized to experimental data, e.g. to the values at kT=25 keV obtained in activation measurements. In these cases the uncertainties should be linearly increased below 25 and above 30 keV to reach about 30% at the extreme kT values.)
Year: 2013

X-factor:
Reference: Rau12
Year: 2012

SEF (Stellar enhancement factor):
Reference: Rau09
Year: 2009
Comment:

Rate:
Reaction rate N_A<σv> given in 10⁷ cm³/mole/s, including SEF

	135La 19.50 h β+ 136La 9.87 m β+ 137La 59.99 ka β+ 138La 102.01x109 y 419 mb, β+ 139La 99.91 31.6 mb 134Ba 2.417 176 mb 135Ba 6.592 455 mb 136Ba 7.854 61.2 mb 137Ba 11.232 76.3 mb 138Ba 71.698 4 mb 133Cs 100 509 mb 134Cs 2.07 a 664 mb, β- 135Cs 2.30 Ma 198 mb, β- 136Cs 13.04 d β- 137Cs 30.03 a β- 132Xe 26.909 64.6 mb 133Xe 5.24 d 127 mb, β- 134Xe 10.436 20.2 mb 135Xe 9.14 h β- 136Xe 8.857 0.91 mb 131I 8.02 d β- 132I 2.29 h β- 133I 20.80 h β- 134I 52.50 m β- 135I 6.57 h β-
